Piedmont Etched Arched Glass Door


Out of stock



Piedmont Etched Arched Glass Door

Our Arched Glass door is a favorite because it takes a standard rectangular wood door with a straight edge and adds an arch to the top to allow for a unique glass door in the center. Add in our elegant Piedmont Etch and you have an exciting design that adds to the ambiance as you walk into your wine cellar. Choose between our standard woods, stains, and lacquer along with various accessories to make your door perfect for you.


Increase the aesthetic value of your wine cellar with our custom built wine cellar doors. Purchasing a properly insulated wine cellar door from us, industry leaders and wine cellar specialists, will ensure your wine cellar will stay sealed properly. We are currently selling this pictured wine cellar door online, at the given dimensions (See Specs). Please contact us for a custom quote if you are looking for a custom sized wine cellar door, we can accommodate most requests.

*NOTE: Door trim does not come standard with a door purchase. Door trim can be purchased separately. Handles and locking mechanisms are not provided but can be purchased here.

Requirements to Receive A Custom Wine Cellar Door Quote
Either the rough opening of your space or the net door dimensions are required if the space is in the framing stage. Jamb width will also be required. Jamb width is simply the thickness of the wall the door will be hung in.

*Also note that if you are purchasing this door or gate, that a representative will need to get in touch with you to have you sign off on a spec sheet. Please make sure that accurate contact information is submitted at checkout so we may do so efficiently and promptly. This spec sheet is required documentation needed prior to placing your order into production.

  • Many custom options available
  • Our wine cellar doors and sidelights are constructed from our signature All-Heart Redwood, Premium Redwood or Mahogany
  • Threshold, door sweep, and insulation stripping provided
  • R5 insulation value

Hinge dimensions:
4″ with 5/8″ radius corner
3 hinges for doors up to 8″h
4 hinges for doors over 8″h

satin brass Satin Nickel Aged Bronze Antique Pewter bright brass

Satin Brass                         Satin Nickel                         Aged Bronze                    Antique Pewter                     Bright Brass

NOTE: Colors shown may vary from the actual product. Please refer to product samples for true color representation.

Trim does not come standard with the purchase of a door. Trim can be finished to match your door or racking. Standard door trim for All-Heart Redwood & Premium Redwood and Mahogany doors only.

standard door trim




This Standard Wine Cellar Door is manufactured utilizing the material shown on this swatch

premium redwood unstainedPremium Redwood

allheart redwood unstainedAll Heart Redwood

Grand Mahogany unstainedMahogany


Standard doorNet door- 32″ x 80″, Rough opening- 34 7/8″ x 83″.
Custom doorPlease call for quote.
Door JambPre-hung with jamb width of your specification. The standard jamb width is 4 9/16″ or 5 1/4″. There will be an up charge for jambs larger. Jambs cannot be less than 3 3/4″.
Door Thickness2″ Thick door.
ThresholdThreshold, door sweep and insulation stripping provided.
Door SwingDoor is hung per customer requirements.
Door LocksetsPre-drilled holes for handles or locking mechanisms are not
provided with the exception of hinges.
InsulationR-5 insulation value.
Door SpecsDoors can be built to any specification with the etching customized to fit your taste.
Glass UnitEtched double paned glass units consist of (2) 3/16″ thick tempered panes with a 3/16″ air gap for a 9/16″ total thickness.
Etched GlassAll etchings are sandblasted. We offer 4 standard etching designs. Each piece is a custom creation and may vary from the original. Choose from our collection of images or provide us with your own artwork such as family initials, family crests and vineyard scenes.
Painted GlassThe inner glass pane can be painted per customer specifications with artwork provided. If a door or sidelight has painted areas, it will be triple paned with the painted piece of glass having paint on both sides, insulated between 2 plain pieces of glass.
Stain & wood optionsStains and woods are available with or without lacquer to match your wine cellar. Please refer to the Finishes Tab.
Minimum Door Width24″
Minimum Sidelight Width
