WineZone Ductless Split 6000a Replacement Evaporator


SKU WRRDS6000a-REP-EVAP Categories ,


The name WineZone Cooling Systems has been discontinued. This is a direct replacement Part. Please Confirm with us that this is the correct part that you require.

 Contact US for Replacement parts.

WineZone Ductless Split 6000a replacement Evaporator

WRRDS6000a Replacement Ductless Split Evaporator (Includes coil, face plate, fan motor, fan wheel, and TXV)


Ductless Evaporator:
• Low noise evaporator fan and remote condenser design
• Economical way to cool, even where installing ductwork is impractical or impossible
• Requires only one small hole through wall to run lines for refrigerant, electric and condensate drain
• Washable filters
• Stylish grille cover is easily detached and cleaned




6000a BTUH Ductless Split Specifications


Wall Mounted Evaporator:

VoltageMotor Output Max.Fuse Min.Wire SizeFilter
208/240-60-138 Watts1514-2 w/GrWashable
  • Receives load voltage from condenser
  • Compatible for use with R-134a refrigerant
  • Drain line is 5/8″ barbed
  • Dimensions: 42 5/8 x 12 3/8 x 8 3/4 – 35lbs

Warranty: 1 year parts only

WineZone 6000a Spec     WZDS6000a Installation Instructions
